lestes::backend_v2::intercode::pi_pi Class Reference

Base class for pi-level pseudoinstruction hierarchy. More...

#include <pi.g.hh>

Inheritance diagram for lestes::backend_v2::intercode::pi_pi:

List of all members.

Public Member Functions
ptr< pi_pi >	psp_get () const
	The method psp_get returns the value of the field pi_pi::psp.
void	psp_set (const ptr< pi_pi > &)
	The method psp_set sets the field pi_pi::psp to the given value.
ptr< pi_pi >	nsp_get () const
	The method nsp_get returns the value of the field pi_pi::nsp.
void	nsp_set (const ptr< pi_pi > &)
	The method nsp_set sets the field pi_pi::nsp to the given value.
ulint	level_get () const
	The method level_get returns the value of the field pi_pi::level.
void	level_set (ulint)
	The method level_set sets the field pi_pi::level to the given value.
virtual ptr< ::lestes::backend_v2::structs::pi_operands >	accept_visitor_pi_pi2pi_operands_gen_base (ptr< visitor_pi_pi2pi_operands_gen_base > v) override
virtual ulint	accept_visitor_pi_pi2ulint_gen_base (ptr< visitor_pi_pi2ulint_gen_base > v) override
virtual ptr< vector< srp< ::lestes::backend_v2::intercode::ge_pi > > >	accept_visitor_pi_pi2ge_pi_gen_base (ptr< visitor_pi_pi2ge_pi_gen_base > v) override
virtual ptr< reflection_list >	reflection_get () const
	for purposes of dumping
virtual ptr< field_list_list >	field_values_get () const
	for purposes of dumping
Protected Member Functions
	pi_pi (ptr< pi_pi > a__pi_pi__psp, ptr< pi_pi > a__pi_pi__nsp, ulint a__pi_pi__level)
	Generated constructor for class pi_pi.
virtual void	gc_mark ()
	Marking routine for class pi_pi.
Private Attributes
srp< pi_pi >	psp
	First boundary sequencepoint.
srp< pi_pi >	nsp
	Second boundary sequencepoint.
ulint	level
	Level for topological ordering of pseudoinstructions.
Static Private Attributes
static ptr< reflection_list >	reflection = reflection

---

Detailed Description

Base class for pi-level pseudoinstruction hierarchy.

Definition at line 219 of file pi.g.hh.

---

Constructor & Destructor Documentation

lestes::backend_v2::intercode::pi_pi::pi_pi	(	ptr< pi_pi >	a__pi_pi__psp,
		ptr< pi_pi >	a__pi_pi__nsp,
		ulint	a__pi_pi__level
	)			[protected]

Generated constructor for class pi_pi.

Generated constructor for class pi_pi.

Author:

lsg

Definition at line 88 of file pi.g.cc.

        : ::lestes::intercode::pi_base(), psp(a__pi_pi__psp), nsp(a__pi_pi__nsp), level(a__pi_pi__level)
{}

---

Member Function Documentation

ptr< pi_pi > lestes::backend_v2::intercode::pi_pi::psp_get

(

)

const

The method psp_get returns the value of the field pi_pi::psp.

Returns:

The value of pi_pi::psp.

Author:

lsg

Definition at line 34 of file pi.g.cc.

References psp.

{
        return psp;
}

void lestes::backend_v2::intercode::pi_pi::psp_set

(

const ptr< pi_pi > &

x

)

The method psp_set sets the field pi_pi::psp to the given value.

Parameters:

[in]

x

The new value to set pi_pi::psp to.

Author:

lsg

Definition at line 43 of file pi.g.cc.

References psp.

{
        pi_pi::psp = x;
}

ptr< pi_pi > lestes::backend_v2::intercode::pi_pi::nsp_get

(

)

const

The method nsp_get returns the value of the field pi_pi::nsp.

Returns:

The value of pi_pi::nsp.

Author:

lsg

Definition at line 52 of file pi.g.cc.

References nsp.

{
        return nsp;
}

void lestes::backend_v2::intercode::pi_pi::nsp_set

(

const ptr< pi_pi > &

x

)

The method nsp_set sets the field pi_pi::nsp to the given value.

Parameters:

[in]

x

The new value to set pi_pi::nsp to.

Author:

lsg

Definition at line 61 of file pi.g.cc.

References nsp.

{
        pi_pi::nsp = x;
}

ulint lestes::backend_v2::intercode::pi_pi::level_get

(

)

const

The method level_get returns the value of the field pi_pi::level.

Returns:

The value of pi_pi::level.

Author:

lsg

Definition at line 70 of file pi.g.cc.

References level.

{
        return level;
}

void lestes::backend_v2::intercode::pi_pi::level_set

(

ulint

x

)

The method level_set sets the field pi_pi::level to the given value.

Parameters:

[in]

x

The new value to set pi_pi::level to.

Author:

lsg

Definition at line 79 of file pi.g.cc.

References level.

{
        pi_pi::level = x;
}

virtual ptr< ::lestes::backend_v2::structs::pi_operands > lestes::backend_v2::intercode::pi_pi::accept_visitor_pi_pi2pi_operands_gen_base

(

ptr< visitor_pi_pi2pi_operands_gen_base >

v

)

[pure virtual]

Implemented in lestes::backend_v2::intercode::pi_branch, lestes::backend_v2::intercode::pi_conditional_branch, lestes::backend_v2::intercode::pi_uconditional_branch, lestes::backend_v2::intercode::pi_branch_multiple, lestes::backend_v2::intercode::pi_cb_single_label_target, lestes::backend_v2::intercode::pi_cb_single_address_target, lestes::backend_v2::intercode::pi_ub_single_label_target, lestes::backend_v2::intercode::pi_ub_single_address_target, lestes::backend_v2::intercode::pi_branch_multiple_label_target, lestes::backend_v2::intercode::pi_branch_multiple_address_target, lestes::backend_v2::intercode::pi_bpi, lestes::backend_v2::intercode::pi_tpi, lestes::backend_v2::intercode::pi_abstract_function_call, lestes::backend_v2::intercode::pi_bdtpi, lestes::backend_v2::intercode::pi_abstract_move, lestes::backend_v2::intercode::pi_abstract_move_st, lestes::backend_v2::intercode::pi_abstract_move_dt, lestes::backend_v2::intercode::pi_indirect_store, lestes::backend_v2::intercode::pi_indirect_load, lestes::backend_v2::intercode::pi_bstpi, lestes::backend_v2::intercode::pi_tstpi, lestes::backend_v2::intercode::pi_tdtpi, lestes::backend_v2::intercode::pi_sp, lestes::backend_v2::intercode::pi_add, lestes::backend_v2::intercode::pi_sub, lestes::backend_v2::intercode::pi_mul, lestes::backend_v2::intercode::pi_div, lestes::backend_v2::intercode::pi_divrni, lestes::backend_v2::intercode::pi_divrpi, lestes::backend_v2::intercode::pi_divrz, lestes::backend_v2::intercode::pi_mod, lestes::backend_v2::intercode::pi_rem, lestes::backend_v2::intercode::pi_neg, lestes::backend_v2::intercode::pi_gat, lestes::backend_v2::intercode::pi_shl, lestes::backend_v2::intercode::pi_shr, lestes::backend_v2::intercode::pi_sal, lestes::backend_v2::intercode::pi_sar, lestes::backend_v2::intercode::pi_band, lestes::backend_v2::intercode::pi_bor, lestes::backend_v2::intercode::pi_bxor, lestes::backend_v2::intercode::pi_bnot, lestes::backend_v2::intercode::pi_land, lestes::backend_v2::intercode::pi_lor, lestes::backend_v2::intercode::pi_lxor, lestes::backend_v2::intercode::pi_lnot, lestes::backend_v2::intercode::pi_cvt, lestes::backend_v2::intercode::pi_cmp, lestes::backend_v2::intercode::pi_mov, lestes::backend_v2::intercode::pi_ld, lestes::backend_v2::intercode::pi_lda, lestes::backend_v2::intercode::pi_ldi, lestes::backend_v2::intercode::pi_ldp, lestes::backend_v2::intercode::pi_ldv, lestes::backend_v2::intercode::pi_ldpv, lestes::backend_v2::intercode::pi_st, lestes::backend_v2::intercode::pi_sti, lestes::backend_v2::intercode::pi_stp, lestes::backend_v2::intercode::pi_stv, lestes::backend_v2::intercode::pi_stiv, lestes::backend_v2::intercode::pi_stpv, lestes::backend_v2::intercode::pi_call, lestes::backend_v2::intercode::pi_icall, lestes::backend_v2::intercode::pi_callv, lestes::backend_v2::intercode::pi_icallv, lestes::backend_v2::intercode::pi_ba, lestes::backend_v2::intercode::pi_bn, lestes::backend_v2::intercode::pi_bt, lestes::backend_v2::intercode::pi_bf, lestes::backend_v2::intercode::pi_bm, lestes::backend_v2::intercode::pi_bg, lestes::backend_v2::intercode::pi_bl, lestes::backend_v2::intercode::pi_be, lestes::backend_v2::intercode::pi_bng, lestes::backend_v2::intercode::pi_bnl, lestes::backend_v2::intercode::pi_bne, lestes::backend_v2::intercode::pi_iba, lestes::backend_v2::intercode::pi_ibn, lestes::backend_v2::intercode::pi_ibm, lestes::backend_v2::intercode::pi_ibg, lestes::backend_v2::intercode::pi_ibl, lestes::backend_v2::intercode::pi_ibe, lestes::backend_v2::intercode::pi_ibng, lestes::backend_v2::intercode::pi_ibnl, lestes::backend_v2::intercode::pi_ibne, lestes::backend_v2::intercode::pi_leave, lestes::backend_v2::intercode::pi_sbg, lestes::backend_v2::intercode::pi_sbl, lestes::backend_v2::intercode::pi_sbe, lestes::backend_v2::intercode::pi_sbng, lestes::backend_v2::intercode::pi_sbnl, and lestes::backend_v2::intercode::pi_sbne.

virtual ulint lestes::backend_v2::intercode::pi_pi::accept_visitor_pi_pi2ulint_gen_base

(

ptr< visitor_pi_pi2ulint_gen_base >

v

)

[pure virtual]

Implemented in lestes::backend_v2::intercode::pi_branch, lestes::backend_v2::intercode::pi_conditional_branch, lestes::backend_v2::intercode::pi_uconditional_branch, lestes::backend_v2::intercode::pi_branch_multiple, lestes::backend_v2::intercode::pi_cb_single_label_target, lestes::backend_v2::intercode::pi_cb_single_address_target, lestes::backend_v2::intercode::pi_ub_single_label_target, lestes::backend_v2::intercode::pi_ub_single_address_target, lestes::backend_v2::intercode::pi_branch_multiple_label_target, lestes::backend_v2::intercode::pi_branch_multiple_address_target, lestes::backend_v2::intercode::pi_bpi, lestes::backend_v2::intercode::pi_tpi, lestes::backend_v2::intercode::pi_abstract_function_call, lestes::backend_v2::intercode::pi_bdtpi, lestes::backend_v2::intercode::pi_abstract_move, lestes::backend_v2::intercode::pi_abstract_move_st, lestes::backend_v2::intercode::pi_abstract_move_dt, lestes::backend_v2::intercode::pi_indirect_store, lestes::backend_v2::intercode::pi_indirect_load, lestes::backend_v2::intercode::pi_bstpi, lestes::backend_v2::intercode::pi_tstpi, lestes::backend_v2::intercode::pi_tdtpi, lestes::backend_v2::intercode::pi_sp, lestes::backend_v2::intercode::pi_add, lestes::backend_v2::intercode::pi_sub, lestes::backend_v2::intercode::pi_mul, lestes::backend_v2::intercode::pi_div, lestes::backend_v2::intercode::pi_divrni, lestes::backend_v2::intercode::pi_divrpi, lestes::backend_v2::intercode::pi_divrz, lestes::backend_v2::intercode::pi_mod, lestes::backend_v2::intercode::pi_rem, lestes::backend_v2::intercode::pi_neg, lestes::backend_v2::intercode::pi_gat, lestes::backend_v2::intercode::pi_shl, lestes::backend_v2::intercode::pi_shr, lestes::backend_v2::intercode::pi_sal, lestes::backend_v2::intercode::pi_sar, lestes::backend_v2::intercode::pi_band, lestes::backend_v2::intercode::pi_bor, lestes::backend_v2::intercode::pi_bxor, lestes::backend_v2::intercode::pi_bnot, lestes::backend_v2::intercode::pi_land, lestes::backend_v2::intercode::pi_lor, lestes::backend_v2::intercode::pi_lxor, lestes::backend_v2::intercode::pi_lnot, lestes::backend_v2::intercode::pi_cvt, lestes::backend_v2::intercode::pi_cmp, lestes::backend_v2::intercode::pi_mov, lestes::backend_v2::intercode::pi_ld, lestes::backend_v2::intercode::pi_lda, lestes::backend_v2::intercode::pi_ldi, lestes::backend_v2::intercode::pi_ldp, lestes::backend_v2::intercode::pi_ldv, lestes::backend_v2::intercode::pi_ldpv, lestes::backend_v2::intercode::pi_st, lestes::backend_v2::intercode::pi_sti, lestes::backend_v2::intercode::pi_stp, lestes::backend_v2::intercode::pi_stv, lestes::backend_v2::intercode::pi_stiv, lestes::backend_v2::intercode::pi_stpv, lestes::backend_v2::intercode::pi_call, lestes::backend_v2::intercode::pi_icall, lestes::backend_v2::intercode::pi_callv, lestes::backend_v2::intercode::pi_icallv, lestes::backend_v2::intercode::pi_ba, lestes::backend_v2::intercode::pi_bn, lestes::backend_v2::intercode::pi_bt, lestes::backend_v2::intercode::pi_bf, lestes::backend_v2::intercode::pi_bm, lestes::backend_v2::intercode::pi_bg, lestes::backend_v2::intercode::pi_bl, lestes::backend_v2::intercode::pi_be, lestes::backend_v2::intercode::pi_bng, lestes::backend_v2::intercode::pi_bnl, lestes::backend_v2::intercode::pi_bne, lestes::backend_v2::intercode::pi_iba, lestes::backend_v2::intercode::pi_ibn, lestes::backend_v2::intercode::pi_ibm, lestes::backend_v2::intercode::pi_ibg, lestes::backend_v2::intercode::pi_ibl, lestes::backend_v2::intercode::pi_ibe, lestes::backend_v2::intercode::pi_ibng, lestes::backend_v2::intercode::pi_ibnl, lestes::backend_v2::intercode::pi_ibne, lestes::backend_v2::intercode::pi_leave, lestes::backend_v2::intercode::pi_sbg, lestes::backend_v2::intercode::pi_sbl, lestes::backend_v2::intercode::pi_sbe, lestes::backend_v2::intercode::pi_sbng, lestes::backend_v2::intercode::pi_sbnl, and lestes::backend_v2::intercode::pi_sbne.

virtual ptr< vector< srp< ::lestes::backend_v2::intercode::ge_pi> > > lestes::backend_v2::intercode::pi_pi::accept_visitor_pi_pi2ge_pi_gen_base

(

ptr< visitor_pi_pi2ge_pi_gen_base >

v

)

[pure virtual]

Implemented in lestes::backend_v2::intercode::pi_branch, lestes::backend_v2::intercode::pi_conditional_branch, lestes::backend_v2::intercode::pi_uconditional_branch, lestes::backend_v2::intercode::pi_branch_multiple, lestes::backend_v2::intercode::pi_cb_single_label_target, lestes::backend_v2::intercode::pi_cb_single_address_target, lestes::backend_v2::intercode::pi_ub_single_label_target, lestes::backend_v2::intercode::pi_ub_single_address_target, lestes::backend_v2::intercode::pi_branch_multiple_label_target, lestes::backend_v2::intercode::pi_branch_multiple_address_target, lestes::backend_v2::intercode::pi_bpi, lestes::backend_v2::intercode::pi_tpi, lestes::backend_v2::intercode::pi_abstract_function_call, lestes::backend_v2::intercode::pi_bdtpi, lestes::backend_v2::intercode::pi_abstract_move, lestes::backend_v2::intercode::pi_abstract_move_st, lestes::backend_v2::intercode::pi_abstract_move_dt, lestes::backend_v2::intercode::pi_indirect_store, lestes::backend_v2::intercode::pi_indirect_load, lestes::backend_v2::intercode::pi_bstpi, lestes::backend_v2::intercode::pi_tstpi, lestes::backend_v2::intercode::pi_tdtpi, lestes::backend_v2::intercode::pi_sp, lestes::backend_v2::intercode::pi_add, lestes::backend_v2::intercode::pi_sub, lestes::backend_v2::intercode::pi_mul, lestes::backend_v2::intercode::pi_div, lestes::backend_v2::intercode::pi_divrni, lestes::backend_v2::intercode::pi_divrpi, lestes::backend_v2::intercode::pi_divrz, lestes::backend_v2::intercode::pi_mod, lestes::backend_v2::intercode::pi_rem, lestes::backend_v2::intercode::pi_neg, lestes::backend_v2::intercode::pi_gat, lestes::backend_v2::intercode::pi_shl, lestes::backend_v2::intercode::pi_shr, lestes::backend_v2::intercode::pi_sal, lestes::backend_v2::intercode::pi_sar, lestes::backend_v2::intercode::pi_band, lestes::backend_v2::intercode::pi_bor, lestes::backend_v2::intercode::pi_bxor, lestes::backend_v2::intercode::pi_bnot, lestes::backend_v2::intercode::pi_land, lestes::backend_v2::intercode::pi_lor, lestes::backend_v2::intercode::pi_lxor, lestes::backend_v2::intercode::pi_lnot, lestes::backend_v2::intercode::pi_cvt, lestes::backend_v2::intercode::pi_cmp, lestes::backend_v2::intercode::pi_mov, lestes::backend_v2::intercode::pi_ld, lestes::backend_v2::intercode::pi_lda, lestes::backend_v2::intercode::pi_ldi, lestes::backend_v2::intercode::pi_ldp, lestes::backend_v2::intercode::pi_ldv, lestes::backend_v2::intercode::pi_ldpv, lestes::backend_v2::intercode::pi_st, lestes::backend_v2::intercode::pi_sti, lestes::backend_v2::intercode::pi_stp, lestes::backend_v2::intercode::pi_stv, lestes::backend_v2::intercode::pi_stiv, lestes::backend_v2::intercode::pi_stpv, lestes::backend_v2::intercode::pi_call, lestes::backend_v2::intercode::pi_icall, lestes::backend_v2::intercode::pi_callv, lestes::backend_v2::intercode::pi_icallv, lestes::backend_v2::intercode::pi_ba, lestes::backend_v2::intercode::pi_bn, lestes::backend_v2::intercode::pi_bt, lestes::backend_v2::intercode::pi_bf, lestes::backend_v2::intercode::pi_bm, lestes::backend_v2::intercode::pi_bg, lestes::backend_v2::intercode::pi_bl, lestes::backend_v2::intercode::pi_be, lestes::backend_v2::intercode::pi_bng, lestes::backend_v2::intercode::pi_bnl, lestes::backend_v2::intercode::pi_bne, lestes::backend_v2::intercode::pi_iba, lestes::backend_v2::intercode::pi_ibn, lestes::backend_v2::intercode::pi_ibm, lestes::backend_v2::intercode::pi_ibg, lestes::backend_v2::intercode::pi_ibl, lestes::backend_v2::intercode::pi_ibe, lestes::backend_v2::intercode::pi_ibng, lestes::backend_v2::intercode::pi_ibnl, lestes::backend_v2::intercode::pi_ibne, lestes::backend_v2::intercode::pi_leave, lestes::backend_v2::intercode::pi_sbg, lestes::backend_v2::intercode::pi_sbl, lestes::backend_v2::intercode::pi_sbe, lestes::backend_v2::intercode::pi_sbng, lestes::backend_v2::intercode::pi_sbnl, and lestes::backend_v2::intercode::pi_sbne.

ptr< object::reflection_list > lestes::backend_v2::intercode::pi_pi::reflection_get

(

)

const [virtual]

for purposes of dumping

Reimplemented from lestes::intercode::pi_base.

Reimplemented in lestes::backend_v2::intercode::pi_branch, lestes::backend_v2::intercode::pi_conditional_branch, lestes::backend_v2::intercode::pi_uconditional_branch, lestes::backend_v2::intercode::pi_branch_multiple, lestes::backend_v2::intercode::pi_cb_single_label_target, lestes::backend_v2::intercode::pi_cb_single_address_target, lestes::backend_v2::intercode::pi_ub_single_label_target, lestes::backend_v2::intercode::pi_ub_single_address_target, lestes::backend_v2::intercode::pi_branch_multiple_label_target, lestes::backend_v2::intercode::pi_branch_multiple_address_target, lestes::backend_v2::intercode::pi_bpi, lestes::backend_v2::intercode::pi_tpi, lestes::backend_v2::intercode::pi_abstract_function_call, lestes::backend_v2::intercode::pi_bdtpi, lestes::backend_v2::intercode::pi_abstract_move, lestes::backend_v2::intercode::pi_abstract_move_st, lestes::backend_v2::intercode::pi_abstract_move_dt, lestes::backend_v2::intercode::pi_indirect_store, lestes::backend_v2::intercode::pi_indirect_load, lestes::backend_v2::intercode::pi_bstpi, lestes::backend_v2::intercode::pi_tstpi, lestes::backend_v2::intercode::pi_tdtpi, lestes::backend_v2::intercode::pi_sp, lestes::backend_v2::intercode::pi_add, lestes::backend_v2::intercode::pi_sub, lestes::backend_v2::intercode::pi_mul, lestes::backend_v2::intercode::pi_div, lestes::backend_v2::intercode::pi_divrni, lestes::backend_v2::intercode::pi_divrpi, lestes::backend_v2::intercode::pi_divrz, lestes::backend_v2::intercode::pi_mod, lestes::backend_v2::intercode::pi_rem, lestes::backend_v2::intercode::pi_neg, lestes::backend_v2::intercode::pi_gat, lestes::backend_v2::intercode::pi_shl, lestes::backend_v2::intercode::pi_shr, lestes::backend_v2::intercode::pi_sal, lestes::backend_v2::intercode::pi_sar, lestes::backend_v2::intercode::pi_band, lestes::backend_v2::intercode::pi_bor, lestes::backend_v2::intercode::pi_bxor, lestes::backend_v2::intercode::pi_bnot, lestes::backend_v2::intercode::pi_land, lestes::backend_v2::intercode::pi_lor, lestes::backend_v2::intercode::pi_lxor, lestes::backend_v2::intercode::pi_lnot, lestes::backend_v2::intercode::pi_cvt, lestes::backend_v2::intercode::pi_cmp, lestes::backend_v2::intercode::pi_mov, lestes::backend_v2::intercode::pi_ld, lestes::backend_v2::intercode::pi_lda, lestes::backend_v2::intercode::pi_ldi, lestes::backend_v2::intercode::pi_ldp, lestes::backend_v2::intercode::pi_ldv, lestes::backend_v2::intercode::pi_ldpv, lestes::backend_v2::intercode::pi_st, lestes::backend_v2::intercode::pi_sti, lestes::backend_v2::intercode::pi_stp, lestes::backend_v2::intercode::pi_stv, lestes::backend_v2::intercode::pi_stiv, lestes::backend_v2::intercode::pi_stpv, lestes::backend_v2::intercode::pi_call, lestes::backend_v2::intercode::pi_icall, lestes::backend_v2::intercode::pi_callv, lestes::backend_v2::intercode::pi_icallv, lestes::backend_v2::intercode::pi_ba, lestes::backend_v2::intercode::pi_bn, lestes::backend_v2::intercode::pi_bt, lestes::backend_v2::intercode::pi_bf, lestes::backend_v2::intercode::pi_bm, lestes::backend_v2::intercode::pi_bg, lestes::backend_v2::intercode::pi_bl, lestes::backend_v2::intercode::pi_be, lestes::backend_v2::intercode::pi_bng, lestes::backend_v2::intercode::pi_bnl, lestes::backend_v2::intercode::pi_bne, lestes::backend_v2::intercode::pi_iba, lestes::backend_v2::intercode::pi_ibn, lestes::backend_v2::intercode::pi_ibm, lestes::backend_v2::intercode::pi_ibg, lestes::backend_v2::intercode::pi_ibl, lestes::backend_v2::intercode::pi_ibe, lestes::backend_v2::intercode::pi_ibng, lestes::backend_v2::intercode::pi_ibnl, lestes::backend_v2::intercode::pi_ibne, lestes::backend_v2::intercode::pi_leave, lestes::backend_v2::intercode::pi_sbg, lestes::backend_v2::intercode::pi_sbl, lestes::backend_v2::intercode::pi_sbe, lestes::backend_v2::intercode::pi_sbng, lestes::backend_v2::intercode::pi_sbnl, and lestes::backend_v2::intercode::pi_sbne.

Definition at line 94 of file pi.g.cc.

References lestes::std::list< T >::create(), reflection, and lestes::intercode::pi_base::reflection_get().

Referenced by lestes::backend_v2::intercode::pi_leave::reflection_get(), lestes::backend_v2::intercode::pi_sp::reflection_get(), lestes::backend_v2::intercode::pi_abstract_move::reflection_get(), lestes::backend_v2::intercode::pi_abstract_function_call::reflection_get(), lestes::backend_v2::intercode::pi_tpi::reflection_get(), lestes::backend_v2::intercode::pi_bpi::reflection_get(), and lestes::backend_v2::intercode::pi_branch::reflection_get().

{
        if (!reflection) {
                typedef class_reflection::field_metadata md;
                typedef class_reflection::field_metadata_list mdlist;
                ptr<mdlist> mdl = mdlist::create();
                mdl->push_back( md::create( "psp", "pi_pi" ) );
                mdl->push_back( md::create( "nsp", "pi_pi" ) );
                mdl->push_back( md::create( "level", "ulint" ) );
                reflection = reflection_list::create( ::lestes::intercode::pi_base::reflection_get() );
                reflection->push_back( class_reflection::create( "pi_pi", mdl ) );
        }
        return reflection;
}

ptr< object::field_list_list > lestes::backend_v2::intercode::pi_pi::field_values_get

(

)

const [virtual]

for purposes of dumping

Reimplemented from lestes::intercode::pi_base.

Reimplemented in lestes::backend_v2::intercode::pi_branch, lestes::backend_v2::intercode::pi_conditional_branch, lestes::backend_v2::intercode::pi_uconditional_branch, lestes::backend_v2::intercode::pi_branch_multiple, lestes::backend_v2::intercode::pi_cb_single_label_target, lestes::backend_v2::intercode::pi_cb_single_address_target, lestes::backend_v2::intercode::pi_ub_single_label_target, lestes::backend_v2::intercode::pi_ub_single_address_target, lestes::backend_v2::intercode::pi_branch_multiple_label_target, lestes::backend_v2::intercode::pi_branch_multiple_address_target, lestes::backend_v2::intercode::pi_bpi, lestes::backend_v2::intercode::pi_tpi, lestes::backend_v2::intercode::pi_abstract_function_call, lestes::backend_v2::intercode::pi_bdtpi, lestes::backend_v2::intercode::pi_abstract_move, lestes::backend_v2::intercode::pi_abstract_move_st, lestes::backend_v2::intercode::pi_abstract_move_dt, lestes::backend_v2::intercode::pi_indirect_store, lestes::backend_v2::intercode::pi_indirect_load, lestes::backend_v2::intercode::pi_bstpi, lestes::backend_v2::intercode::pi_tstpi, lestes::backend_v2::intercode::pi_tdtpi, lestes::backend_v2::intercode::pi_sp, lestes::backend_v2::intercode::pi_add, lestes::backend_v2::intercode::pi_sub, lestes::backend_v2::intercode::pi_mul, lestes::backend_v2::intercode::pi_div, lestes::backend_v2::intercode::pi_divrni, lestes::backend_v2::intercode::pi_divrpi, lestes::backend_v2::intercode::pi_divrz, lestes::backend_v2::intercode::pi_mod, lestes::backend_v2::intercode::pi_rem, lestes::backend_v2::intercode::pi_neg, lestes::backend_v2::intercode::pi_gat, lestes::backend_v2::intercode::pi_shl, lestes::backend_v2::intercode::pi_shr, lestes::backend_v2::intercode::pi_sal, lestes::backend_v2::intercode::pi_sar, lestes::backend_v2::intercode::pi_band, lestes::backend_v2::intercode::pi_bor, lestes::backend_v2::intercode::pi_bxor, lestes::backend_v2::intercode::pi_bnot, lestes::backend_v2::intercode::pi_land, lestes::backend_v2::intercode::pi_lor, lestes::backend_v2::intercode::pi_lxor, lestes::backend_v2::intercode::pi_lnot, lestes::backend_v2::intercode::pi_cvt, lestes::backend_v2::intercode::pi_cmp, lestes::backend_v2::intercode::pi_mov, lestes::backend_v2::intercode::pi_ld, lestes::backend_v2::intercode::pi_lda, lestes::backend_v2::intercode::pi_ldi, lestes::backend_v2::intercode::pi_ldp, lestes::backend_v2::intercode::pi_ldv, lestes::backend_v2::intercode::pi_ldpv, lestes::backend_v2::intercode::pi_st, lestes::backend_v2::intercode::pi_sti, lestes::backend_v2::intercode::pi_stp, lestes::backend_v2::intercode::pi_stv, lestes::backend_v2::intercode::pi_stiv, lestes::backend_v2::intercode::pi_stpv, lestes::backend_v2::intercode::pi_call, lestes::backend_v2::intercode::pi_icall, lestes::backend_v2::intercode::pi_callv, lestes::backend_v2::intercode::pi_icallv, lestes::backend_v2::intercode::pi_ba, lestes::backend_v2::intercode::pi_bn, lestes::backend_v2::intercode::pi_bt, lestes::backend_v2::intercode::pi_bf, lestes::backend_v2::intercode::pi_bm, lestes::backend_v2::intercode::pi_bg, lestes::backend_v2::intercode::pi_bl, lestes::backend_v2::intercode::pi_be, lestes::backend_v2::intercode::pi_bng, lestes::backend_v2::intercode::pi_bnl, lestes::backend_v2::intercode::pi_bne, lestes::backend_v2::intercode::pi_iba, lestes::backend_v2::intercode::pi_ibn, lestes::backend_v2::intercode::pi_ibm, lestes::backend_v2::intercode::pi_ibg, lestes::backend_v2::intercode::pi_ibl, lestes::backend_v2::intercode::pi_ibe, lestes::backend_v2::intercode::pi_ibng, lestes::backend_v2::intercode::pi_ibnl, lestes::backend_v2::intercode::pi_ibne, lestes::backend_v2::intercode::pi_leave, lestes::backend_v2::intercode::pi_sbg, lestes::backend_v2::intercode::pi_sbl, lestes::backend_v2::intercode::pi_sbe, lestes::backend_v2::intercode::pi_sbng, lestes::backend_v2::intercode::pi_sbnl, and lestes::backend_v2::intercode::pi_sbne.

Definition at line 109 of file pi.g.cc.

References lestes::std::list< T >::create(), and lestes::intercode::pi_base::field_values_get().

Referenced by lestes::backend_v2::intercode::pi_leave::field_values_get(), lestes::backend_v2::intercode::pi_sp::field_values_get(), lestes::backend_v2::intercode::pi_abstract_move::field_values_get(), lestes::backend_v2::intercode::pi_abstract_function_call::field_values_get(), lestes::backend_v2::intercode::pi_tpi::field_values_get(), lestes::backend_v2::intercode::pi_bpi::field_values_get(), and lestes::backend_v2::intercode::pi_branch::field_values_get().

{
        ptr < field_list_list > result = ::lestes::intercode::pi_base::field_values_get();
        result->push_back( value_list::create() );
        result->back()->push_back( this->psp );
        result->push_back( value_list::create() );
        result->back()->push_back( this->nsp );
        result->push_back( value_list::create() );
        result->back()->push_back( objectize< ulint > ::create( this->level ) );
        return result;
}

void lestes::backend_v2::intercode::pi_pi::gc_mark

(

void

)

[protected, virtual]

Marking routine for class pi_pi.

Marking routine is used for garbage collection.

Author:

lsg

Reimplemented from lestes::intercode::pi_base.

Reimplemented in lestes::backend_v2::intercode::pi_branch, lestes::backend_v2::intercode::pi_conditional_branch, lestes::backend_v2::intercode::pi_uconditional_branch, lestes::backend_v2::intercode::pi_branch_multiple, lestes::backend_v2::intercode::pi_cb_single_label_target, lestes::backend_v2::intercode::pi_cb_single_address_target, lestes::backend_v2::intercode::pi_ub_single_label_target, lestes::backend_v2::intercode::pi_ub_single_address_target, lestes::backend_v2::intercode::pi_branch_multiple_label_target, lestes::backend_v2::intercode::pi_branch_multiple_address_target, lestes::backend_v2::intercode::pi_bpi, lestes::backend_v2::intercode::pi_tpi, lestes::backend_v2::intercode::pi_abstract_function_call, lestes::backend_v2::intercode::pi_bdtpi, lestes::backend_v2::intercode::pi_abstract_move, lestes::backend_v2::intercode::pi_abstract_move_st, lestes::backend_v2::intercode::pi_abstract_move_dt, lestes::backend_v2::intercode::pi_indirect_store, lestes::backend_v2::intercode::pi_indirect_load, lestes::backend_v2::intercode::pi_bstpi, lestes::backend_v2::intercode::pi_tstpi, lestes::backend_v2::intercode::pi_tdtpi, lestes::backend_v2::intercode::pi_sp, lestes::backend_v2::intercode::pi_add, lestes::backend_v2::intercode::pi_sub, lestes::backend_v2::intercode::pi_mul, lestes::backend_v2::intercode::pi_div, lestes::backend_v2::intercode::pi_divrni, lestes::backend_v2::intercode::pi_divrpi, lestes::backend_v2::intercode::pi_divrz, lestes::backend_v2::intercode::pi_mod, lestes::backend_v2::intercode::pi_rem, lestes::backend_v2::intercode::pi_neg, lestes::backend_v2::intercode::pi_gat, lestes::backend_v2::intercode::pi_shl, lestes::backend_v2::intercode::pi_shr, lestes::backend_v2::intercode::pi_sal, lestes::backend_v2::intercode::pi_sar, lestes::backend_v2::intercode::pi_band, lestes::backend_v2::intercode::pi_bor, lestes::backend_v2::intercode::pi_bxor, lestes::backend_v2::intercode::pi_bnot, lestes::backend_v2::intercode::pi_land, lestes::backend_v2::intercode::pi_lor, lestes::backend_v2::intercode::pi_lxor, lestes::backend_v2::intercode::pi_lnot, lestes::backend_v2::intercode::pi_cvt, lestes::backend_v2::intercode::pi_cmp, lestes::backend_v2::intercode::pi_mov, lestes::backend_v2::intercode::pi_ld, lestes::backend_v2::intercode::pi_lda, lestes::backend_v2::intercode::pi_ldi, lestes::backend_v2::intercode::pi_ldp, lestes::backend_v2::intercode::pi_ldv, lestes::backend_v2::intercode::pi_ldpv, lestes::backend_v2::intercode::pi_st, lestes::backend_v2::intercode::pi_sti, lestes::backend_v2::intercode::pi_stp, lestes::backend_v2::intercode::pi_stv, lestes::backend_v2::intercode::pi_stiv, lestes::backend_v2::intercode::pi_stpv, lestes::backend_v2::intercode::pi_call, lestes::backend_v2::intercode::pi_icall, lestes::backend_v2::intercode::pi_callv, lestes::backend_v2::intercode::pi_icallv, lestes::backend_v2::intercode::pi_ba, lestes::backend_v2::intercode::pi_bn, lestes::backend_v2::intercode::pi_bt, lestes::backend_v2::intercode::pi_bf, lestes::backend_v2::intercode::pi_bm, lestes::backend_v2::intercode::pi_bg, lestes::backend_v2::intercode::pi_bl, lestes::backend_v2::intercode::pi_be, lestes::backend_v2::intercode::pi_bng, lestes::backend_v2::intercode::pi_bnl, lestes::backend_v2::intercode::pi_bne, lestes::backend_v2::intercode::pi_iba, lestes::backend_v2::intercode::pi_ibn, lestes::backend_v2::intercode::pi_ibm, lestes::backend_v2::intercode::pi_ibg, lestes::backend_v2::intercode::pi_ibl, lestes::backend_v2::intercode::pi_ibe, lestes::backend_v2::intercode::pi_ibng, lestes::backend_v2::intercode::pi_ibnl, lestes::backend_v2::intercode::pi_ibne, lestes::backend_v2::intercode::pi_leave, lestes::backend_v2::intercode::pi_sbg, lestes::backend_v2::intercode::pi_sbl, lestes::backend_v2::intercode::pi_sbe, lestes::backend_v2::intercode::pi_sbng, lestes::backend_v2::intercode::pi_sbnl, and lestes::backend_v2::intercode::pi_sbne.

Definition at line 126 of file pi.g.cc.

References lestes::intercode::pi_base::gc_mark().

Referenced by lestes::backend_v2::intercode::pi_leave::gc_mark(), lestes::backend_v2::intercode::pi_sp::gc_mark(), lestes::backend_v2::intercode::pi_abstract_move::gc_mark(), lestes::backend_v2::intercode::pi_abstract_function_call::gc_mark(), lestes::backend_v2::intercode::pi_tpi::gc_mark(), lestes::backend_v2::intercode::pi_bpi::gc_mark(), and lestes::backend_v2::intercode::pi_branch::gc_mark().

{
	::lestes::intercode::pi_base::gc_mark();
}

---

Member Data Documentation

srp< pi_pi > lestes::backend_v2::intercode::pi_pi::psp [private]

First boundary sequencepoint.

Each pseudoinstruction has origin in some C++ expression. Every expression has its boundary sequencepoints. So all pseudoinstructions created from single expression have the same boundary sequencepoints. These sequencepoints guarantee that pseudoinstruction is not scheduled outside its context.

Definition at line 267 of file pi.g.hh.

Referenced by psp_get(), and psp_set().

srp< pi_pi > lestes::backend_v2::intercode::pi_pi::nsp [private]

Second boundary sequencepoint.

Each pseudoinstruction has origin in some C++ expression. Every expression has its boundary sequencepoints. So all pseudoinstructions created from single expression have the same boundary sequencepoints. These sequencepoints guarantee that pseudoinstruction is not scheduled outside its context.

Definition at line 275 of file pi.g.hh.

Referenced by nsp_get(), and nsp_set().

ulint lestes::backend_v2::intercode::pi_pi::level [private]

Level for topological ordering of pseudoinstructions.

Definition at line 277 of file pi.g.hh.

Referenced by level_get(), and level_set().

ptr< object::reflection_list > lestes::backend_v2::intercode::pi_pi::reflection = reflection [static, private]

Reimplemented from lestes::intercode::pi_base.

Reimplemented in lestes::backend_v2::intercode::pi_branch, lestes::backend_v2::intercode::pi_conditional_branch, lestes::backend_v2::intercode::pi_uconditional_branch, lestes::backend_v2::intercode::pi_branch_multiple, lestes::backend_v2::intercode::pi_cb_single_label_target, lestes::backend_v2::intercode::pi_cb_single_address_target, lestes::backend_v2::intercode::pi_ub_single_label_target, lestes::backend_v2::intercode::pi_ub_single_address_target, lestes::backend_v2::intercode::pi_branch_multiple_label_target, lestes::backend_v2::intercode::pi_branch_multiple_address_target, lestes::backend_v2::intercode::pi_bpi, lestes::backend_v2::intercode::pi_tpi, lestes::backend_v2::intercode::pi_abstract_function_call, lestes::backend_v2::intercode::pi_bdtpi, lestes::backend_v2::intercode::pi_abstract_move, lestes::backend_v2::intercode::pi_abstract_move_st, lestes::backend_v2::intercode::pi_abstract_move_dt, lestes::backend_v2::intercode::pi_indirect_store, lestes::backend_v2::intercode::pi_indirect_load, lestes::backend_v2::intercode::pi_bstpi, lestes::backend_v2::intercode::pi_tstpi, lestes::backend_v2::intercode::pi_tdtpi, lestes::backend_v2::intercode::pi_sp, lestes::backend_v2::intercode::pi_add, lestes::backend_v2::intercode::pi_sub, lestes::backend_v2::intercode::pi_mul, lestes::backend_v2::intercode::pi_div, lestes::backend_v2::intercode::pi_divrni, lestes::backend_v2::intercode::pi_divrpi, lestes::backend_v2::intercode::pi_divrz, lestes::backend_v2::intercode::pi_mod, lestes::backend_v2::intercode::pi_rem, lestes::backend_v2::intercode::pi_neg, lestes::backend_v2::intercode::pi_gat, lestes::backend_v2::intercode::pi_shl, lestes::backend_v2::intercode::pi_shr, lestes::backend_v2::intercode::pi_sal, lestes::backend_v2::intercode::pi_sar, lestes::backend_v2::intercode::pi_band, lestes::backend_v2::intercode::pi_bor, lestes::backend_v2::intercode::pi_bxor, lestes::backend_v2::intercode::pi_bnot, lestes::backend_v2::intercode::pi_land, lestes::backend_v2::intercode::pi_lor, lestes::backend_v2::intercode::pi_lxor, lestes::backend_v2::intercode::pi_lnot, lestes::backend_v2::intercode::pi_cvt, lestes::backend_v2::intercode::pi_cmp, lestes::backend_v2::intercode::pi_mov, lestes::backend_v2::intercode::pi_ld, lestes::backend_v2::intercode::pi_lda, lestes::backend_v2::intercode::pi_ldi, lestes::backend_v2::intercode::pi_ldp, lestes::backend_v2::intercode::pi_ldv, lestes::backend_v2::intercode::pi_ldpv, lestes::backend_v2::intercode::pi_st, lestes::backend_v2::intercode::pi_sti, lestes::backend_v2::intercode::pi_stp, lestes::backend_v2::intercode::pi_stv, lestes::backend_v2::intercode::pi_stiv, lestes::backend_v2::intercode::pi_stpv, lestes::backend_v2::intercode::pi_call, lestes::backend_v2::intercode::pi_icall, lestes::backend_v2::intercode::pi_callv, lestes::backend_v2::intercode::pi_icallv, lestes::backend_v2::intercode::pi_ba, lestes::backend_v2::intercode::pi_bn, lestes::backend_v2::intercode::pi_bt, lestes::backend_v2::intercode::pi_bf, lestes::backend_v2::intercode::pi_bm, lestes::backend_v2::intercode::pi_bg, lestes::backend_v2::intercode::pi_bl, lestes::backend_v2::intercode::pi_be, lestes::backend_v2::intercode::pi_bng, lestes::backend_v2::intercode::pi_bnl, lestes::backend_v2::intercode::pi_bne, lestes::backend_v2::intercode::pi_iba, lestes::backend_v2::intercode::pi_ibn, lestes::backend_v2::intercode::pi_ibm, lestes::backend_v2::intercode::pi_ibg, lestes::backend_v2::intercode::pi_ibl, lestes::backend_v2::intercode::pi_ibe, lestes::backend_v2::intercode::pi_ibng, lestes::backend_v2::intercode::pi_ibnl, lestes::backend_v2::intercode::pi_ibne, lestes::backend_v2::intercode::pi_leave, lestes::backend_v2::intercode::pi_sbg, lestes::backend_v2::intercode::pi_sbl, lestes::backend_v2::intercode::pi_sbe, lestes::backend_v2::intercode::pi_sbng, lestes::backend_v2::intercode::pi_sbnl, and lestes::backend_v2::intercode::pi_sbne.

Definition at line 278 of file pi.g.hh.

Referenced by reflection_get().

---

The documentation for this class was generated from the following files:

• pi.g.hh
• pi.g.cc

---
